Socalled 'standard' bridge types were developed by British Rail from the 1950s onwards and although there is currently only one true standard bridge type in common use, features of many of the others are still appropriate Section 4 presents a brief review of all the main forms of constructionGreece Corinth Canal submersible bridge (Wikipedia) A bridge can be classified as a deck type or through type A deck type bridge is the one in which the roadway/railway floor rests on the top of the supporting structures, while a through bridge is the one where the roadway/railway floor rests on the bottom of the main load supporting structureThe goals of this project were to reuse the historic bridge structure after widening the Santa Paula Creek and minimize the down time of the local railroad company To accommodate these goals, new concrete substructures were built under the existing bridge and approaches for a two span bridge that would reuse the existing steel truss for one span
